Motor: 60Hz, TEFC, 1.75 HP, 120v, 14 A (user config. to 220v w/optional kit available for purchase)
Overall saw dimensions: 58-1/2" W x 40" D x 34-3/4" H
Saw body w/stand footprint: 25-3/4" W x 27" D
Cast iron table: 20" W x 27" D
Cast iron table (w/ extension wings): 44" W x 27" D
Stamped Steel Wings: 12" W x 27" D (opt cast iron for purchase)
Extension table: N/A
Assembled weight: 245 lbs.
Weight – table saw only: 225 lbs.
Blade: 40-tooth, prof. grade, 5/8" arbor
Blade diameter: 10"
Blade tilt: Left
Blade kerf: 0.118" (3mm)
Blade plate thickness: 0.078" (2mm)
Max. depth of cut, blade at 0º: 3-1/8"
Max. depth of cut, blade at 45º: 2-1/4"
Max. rip, left of blade: 16-1/2"
Dado diameter: 8" (req. dado brake + insert)
Dado max. width: 13/16"
Arbor diameter at blade: 5/8"
Main bearing size: 62 mm OD x 30 mm ID
Second bearing size: 52 mm OD x 25 mm ID
Table in front of blade (max. elevation): 10-5/8"
Table behind blade (max. elevation): 7-1/8"
Arbor Runout: 0.001" Maximum allowable runout
Table flatness measured diagonally: 0.016" Maximum gap
Blade alignment with miter slot: 0.010" Maximum displacement
Deviation of miter gauge indexing stops from actual: +/- 0.25 degrees
Alignment between splitter and blade: 0.010" Maximum difference
Miter slots T-shaped: 3/4" at top, 1" at bottom, 3/8" deep
Miter slots center: 11-1/8" center-to-center
Miter slots info: 5-1/2" (arbor flange to center of right slot)
Dust collection port diameter: 4" under table top
Riving knife / splitter thickness: 0.090" (2.3 mm)
Micro blade guard: polycarbonate, extends 1" right of blade (opt dust guard for purchase)
Insert: zero clearance, phenolic core, melamine surfaces
Hand wheels: 6" diameter, cast alum. w/ ABS handle
Belts: V-ribbed belt – static dissipative
Warranty: 1 year
