Motor : PCS175: 1.75 HP, 120v, 14 A (user config. to 220v w/optional kit available for purchase).
Overall saw dimensions : 30 in: 61 3/4" W x 31 1/8" D x 34" H
Saw body footprint: 19 3/8" W x 19 3/8" D (Cabinet)
Cast iron table: 20" W x 27" D
Extension wings: 12" W x 27" D each
Cast iron table (w/ extension wings): 44" W x 27" D
Blade: 40-tooth, prof. grade, 5/8" arbor
Blade diameter: 10"
Blade tilt: Left
Blade kerf: 0.118" (3mm)
Max. depth of cut, blade at 0º: 3 1/8"
Max. depth of cut, blade at 45º: 2 1/4"
Max. rip, right of blade – 30 in: 30" (w/ 30" rails)
Max. rip, left of blade: 12"
Dado diameter: 8" (requires dado brake cartridge & insert)
Dado max. width: 13/16
Arbor diameter at blade: 5/8"
Main bearing size: 62mm OD x 30mm ID
Second bearing size: 52mm OD x 25mm ID
Table in front of blade (max. elevation): 10 1/4"
Table behind blade (max. elevation): 7 1/2"
Arbor Runout: 0.001" Maximum allowable runout
Table flatness measured diagonally: 0.010" Maximum gap
Blade alignment with miter slot: 0.010" Maximum displacement
Deviation of miter gauge indexing stops from actual: ±0.25º
Alignment between splitter and blade: 0.010" Maximum difference
Miter slots T-shaped: 3/4" at top, 1" at bottom, 3/8" deep
Miter slots center: 11 1/8" center-to-center
Miter slots info: 5 1/2" (arbor flange to center of right slot)
Dust collection port diameter: 4"
Riving knife / splitter thickness: 0.090" (2.3 mm)
Dust collection blade guard (standard on 3 HP saws)(optional on 1.75 HP saws): polycarbonate, extends 1-3/16" right of blade
Blade guard: (dust collection) port diameter 1-1/2" Outside, 1-1/4" Inside
Insert: zero clearance, phenolic core, melamine surfaces
Micro blade guard (standard on 1.75 HP saws): polycarbonate, extends 1" right of blade
Hand wheels: 7" diameter, cast iron w/ chrome handle
Belts: 2 V-ribbed belts – arbor b. static dissipative
