14” BANDSAW 10-1414 has many NEW features that woodworkers will enjoy – including NEW SP Coated Table for corrosion protection and reduced friction, NEW Quick Adjust Drift 6” Tall Fence System with Micro-Adustment, NEW enhanced Blade Tension System with quick release blade tension lever, INCREASED 14” Cutting Capacity under the spring-loaded tool-less blade guides, and Two Dust ports. Plus NEW hinged safety Blade Guard with Magnetic Closure and UPDATED Storage Cabinet base. Its dual voltage, 1-3/4 HP motor provides ample power for most every
work encountered. Designed with two NEW speed options – 1,476 / 3,280 ft/min.
Specifications
Tech Specs
Motor Horsepower 1-3/4 HP TEFC
Motor Amps 14/7
Motor Volts 115/230V, 60Hz, 1Ph
Blade Speed 1,476 / 3,280 ft/min
Cutting Capacity Height 14”
Cutting Capacity Width 13-5/8”
Blade Width 3/16” – 3/4”
Blade Length 111”
Table Size 21-1/2” x 15-3/4”
Table Left Tilt -7°
Table Right Tilt 45°
Table Miter Gauge "T" Slot (2) 3/4” x 3/8”
Table Height to Floor 40-1/2”
Table Height to Base 20-7/8”
Table Fence Size 18-3/4” x 1-7/8” x 6”
Wheel Material Cast Iron
Blade Guide Type Spring Loaded
Table Trunnion Cast Iron
Overall Height 76”
Overall Width 33-3/4”
Overall Depth 25”
Overall Base Size 24” x 17-5/8”
Dust Port 1 @ 2-1/2” & 1 @ 4”
Overall Net Weight 303.6 lbs.
Warranty Lifetime
