Laguna 14|BX Bandsaw 1.75 hp – 110 volt

Sale!

Laguna 14|BX Bandsaw 1.75 hp – 110 volt

Original price was: $1,999.00.Current price is: $1,799.10.

In stock!

Ships for $199

The Laguna 14|BX is a bandsaw of uncompromised quality that brings industrial features to woodworkers in home shops and pro shops alike. Though similar to the Laguna 14|12, the 14|BX features a heavier one-piece frame, a first-of-its-kind disc brake to quickly bring the blade to a stop, and dual light mounting positions (lights sold separately). Laguna’s famous pyramid-shaped spine and an oversized trunnion offer incredible rigidity for vibration-free performance. The solid cast iron wheels also dampen vibration, are precisely balanced, and are fitted with polyurethane tires that run cooler and last longer. The generously sized table is micro-polished to a beautiful sheen and includes a precision fence that can be flipped vertically for resawing, or horizontally for standard ripping. The magnetic blade guard is raised and lowered with a worm-drive rack and pinion so your blade guides stay perfectly adjusted regardless of the height. The saw includes Laguna’s renowned ceramic blade guide system. A huge, quick release lever relieves tension for fast blade changes, while convenient viewing windows allow you to check both tension and tracking while the machine is running.



SKU: MBAND14BX110-175 Categories: , Tags: ,

FEATURES

  • 12 Resaw
  • Height: 70 ¼
  • Blade Length: 115
  • Cast Iron Wheels
  • Magnetic Starter
  • Dual Light Mount
  • 45° Table Tilt Right
  • Pyramid-Shaped Spine
  • Footprint: 17 ½ X 22 ½
  • Quick Release Tension
  • Magnetic Blade Guard
  • Laguna Ceramic Guides
  • Hi/Low aluminum Fence
  • Worm Gear Rack & Pinion
  • Massive Cast Trunion 8 X13
Machine Specs

Motor voltage/HP: 115V / 1-3/4HP
Breaker: 15 amp
Height: 5.9ft. (70.5”)
Cast iron table: 21-1/2” X 16” (406.4 mm x 546 mm)
Table Height: 38” (965 mm)
Table tilt: -7° + 45°
Resaw capacity: 13” (330.2 mm)
Min. blade length: 114 3/4" (2,914 mm)
Max. blade length: 116” (2,946 mm)
Min. blade width: 1/8” (3 mm)
Max. blade width: 3/4” (19 mm)
Height: 5.9ft. (70.5”)
Dust collection: 2 x 4" ports
Machine dimensions (W x D): 29-3/4" x 26-7/8" (755 mm x 683 mm)
Net weight: 260 lbs. (118 kg)
