2020B Lathe, 2HP, 1 or 3PH, 220V

2020B Lathe, 2HP, 1 or 3PH, 220V


In stock!

The features you love on the 3520B lathe are now available in a smaller footprint. The PM2020 lathe is perfect for turners short on space, or projects where a short bed is convenient. Like its big brother, the PM2020 features a sliding headstock, electronic variable speed with low and high speed ranges, and the spindle lock. The enhanced features include a digital RPM readout, built in spindle indexing on the head stock, and a re-designed tailstock with internal storage, chrome trimmed handwheels, and a laser etched quill which is self-ejecting. Additional features include a two position mount for the optional bed extension, a sliding hammer knockout rod with brass tip, an attached tool caddy and a metal shelf for tool storage.

• Sliding headstock with electronic variable speed
• Digital RPM readout for accurate speed adjustments
• Tailstock has internal storage for additional accessories and attached tool caddy allows convenient access to centers and wrenches
• Spindle lock and built in spindle indexing on the headstock for drilling hole patterns, routing flutes and other equally spaced features
• Two position mount for optional bed extension
• Chrome trimmed handwheels are ergonomic for a comfortable feel
• Set of dead centers which hold a spindle for visual comparison
• Redesigned tool rest geometry allows for better chisel movement along the tool rest
• Laser etched quill is self-ejecting.
• Brass tipped knockout bar concentrates the action in the sliding handle; the brass tip will not damage drive centers

Machine Specs

Style (Type) Leg Stand
Swing Over Bed (In.) 20
Swing Over Tool Rest Base (In.) 17
Distance Between Centers (In.) 20
Headstock Movement Full Length of Bed
Spindle Bore 5/8
Tailstock Bore 3/8
Spindle Taper MT-2
Quill Taper MT-2
Ram Travel Quill Travel 4-1/2
Spindle Threads (In. x TPI) 1-1/4 x 8 TPI
Outboard External Threads (In. x TPI) 1-3/16-18 UNC
Spindle Speeds High 125-3200/Low 50-1200
Speed Range 50-1200, 125-3200
Number of Indexing Positions 48
Centerline of Spindle to Floor (In.) 44 (adjustable)
Outboard Turning 38
Bed Construction Cast Iron
Motor Power (HP) 2
Motor Phase 3
Motor Voltage (V.) 230 only
Prewired Voltage (V.) 230 only
Wiring Remarks VFD will accept 1 or 3 phase power
Motor Current (Amps) 6.2
Recommended Circuit Size (Amps.) 20
