Enhance your woodworking capabilities with this versatile machine.   This CNC router offers 3D carving capability with a 3D model library included.   You can cut beautiful relief carvings, intricate inlays, and create exquisitely detailed engravings with ease.

The Shark HD520® creative potential is endless.   Beginners to professionals are incorporating this diverse woodworking tool for custom parts, joinery, precision drilling functions, or all things decorative.

The Shark HD520® offers two control options.

1. Using the included VCarve Pro Design Software, you create your project and transfer it to a USB drive which plugs directly into the LCD pendant. The convenient touch screen Pendant interface eliminates the need for a computer controlling the CNC in your shop.
2. For more control interactivity you can run the Shark HD520® from your computer with the Ready2Control program. This lets you use the exclusive patented Virtual Zero Unlimited® program.  Next Wave CNC’s program will adjust your design to fit curves and angles that would be impossible on other brands of machines. (Computer and flash drive not included).

The Shark HD520 ® is the perfect tool for carving or machining a large variety of projects made from wood, soft metals, composites, or plastics.  It is fully compatible with Next Wave CNC’s extensive product line of additional accessories, such as a spindle, laser, 4th axis, digital probe and drawing tool.

The Shark HD520 ® is made in the USA and includes USA Based Technical Support for the Original Owner.

Specifications:

• Table dimensions: 28” x 63”
• XYZ travel: 25” x 50” x 7”
• Overall dimensions: 36-1/4” W x 63” L x 24-1/2” H
• Color Touch Screen pendant controller system
• Router/Spindle on/off is controlled by the software and machine controller.
• Built with industrial-grade components, the SHARK HD520® also features a heavy-duty aluminum and steel reinforced gantry, a new extruded aluminum router mount system, interlocking aluminum table, linear rails, and guides on the gantry, and anti-backlash, wear-compensated lead screws on all axis.
• Built to handle larger 2.25 HP routers with 3.5” barrel diameter like DeWalt 610, 616, 618, PC 890 Series, Bosch 1617 or 1618 (router sold separately)

Included:

• The latest edition of Vectric Vcarve Pro design software $699 Value now incorporating Cut 3D functionality and Vector Art 3D Sampler Pack
• Ready2Control Software– to control your machine with a PC if desired. Also, Virtual Zero Unlimited, $149 value, this patented Next Wave exclusive software allows you to map the surface of your material by taking an unlimited number of reference points. The program then uses these points to auto-adjust the G-code to conform to the actual surface of your material. This eliminates problems caused by a warped or bowed work piece and allows you to maintain a constant cutting depth on projects that other machines would not be able to handle. (Requires a PC computer with USB 2.0 port (not included))
• Interlocking slotted rigid aluminum table allows virtually unlimited clamp positioning
• 2 hold down clamps
• Carbide V Bit.
• Made in the USA
• 2 Year Warranty
• U.S. Based Technical Support

Compatible Accessories

2 HP Spindles
2 Watt Laser
3 HP Spindles
3D Digitizing Probe
7 Watt Laser
10 Watt Laser
10.1 Color Touch Screen Pendant
Shark Tooth Drawing Tool
4th Axis
Mini 4th Axis
Touch Plate
Mini Touch Plate
Vacuum Pods
